Fixed speed 5 .5kw 7.5hp Portable stable Screw Air Compressor with wheels

Short Description:

OPPAIR’s 5.5kw 7.5hp two-in-one pulley air compressor product supports single-phase power use. It integrates the air compressor and air tank into one machine, and is equipped with a low-noise motor. The efficiency is 3%-5% higher than similar products .

The biggest feature is that it is also equipped with ultra-quiet wheels that will not make noise. Touch screen or button screen intelligent control panel, easy to operate, and the running status is clear at a glance.

OPPAIR is trustworthy.

Send email to us

Product Detail

OPPAIR factory introduction

OPPAIR customer feedback

Product Tags

Product description

Support customization, can provide customized production of colors and accessories.

Has a large-capacity gas storage tank. Large capacity, more energy-saving, thicker material, cushioning, stable air pressure.

Equipped with a high-power fan to quickly cool down the temperature inside the machine and extend the lubricating oil replacement cycle.

Low-noise motor, durable, 3%-5% higher efficiency than similar products.

High-quality large-volume oil-gas separator ensures stable oil output and is not easy to block.

Our motors are 100% copper, and the alloy steel pipe connection has stable performance and corrosion resistance.

Equipped with wheels, easy to move. Multiple low powers can be selected.

Product Parameters 2in1

Model	OPN-5F	OPN-6F	OPN-7F	OPN-10F	OPN-15F	OPN-5PV	OPN-6PV	OPN-7PV	OPN-10PV	OPN-15PV
Power(kw)	3.7	4.5	5.5	7.5	11	3.7	4.5	5.5	7.5	11
Horsepower(hp)	5	6	7.5	10	15	5	6	7.5	10	15
Air displacement/ Working pressure (m³/min. / Bar)	0.6/7	0.67/7	0.98/7	1.2/7	1.6/7	0.6/7	0.67/7	0.98/7	1.2/7	1.6/7
	0.58/8	0.63/8	0.95/8	1.1/8	1.5/8	0.58/8	0.63/8	0.95/8	1.1/8	1.5/8
	0.55/10	0.59/10	0.92/10	0.9/10	1.3/10	0.55/10	0.59/10	0.92/10	0.9/10	1.3/10
	0.49/12	0.52/12	0.84/12	0.8/12	1.1/12	0.49/12	0.52/12	0.84/12	0.8/12	1.1/12
Air Tank（L）	120	120	200	200	220	120	120	200	200	220
Type	Fixed Speed	Fixed Speed	Fixed Speed	Fixed Speed	Fixed Speed	PM VSD	PM VSD	PM VSD	PM VSD	PM VSD
Air outlet diameter	DN20	DN20	DN20	DN20	DN40	DN20	DN20	DN20	DN20	DN40
Lubricating oil volume (L)	10	10	10	10	16	10	10	10	10	16
Noise level dB(A)	56±2	56±2	60±2	60±2	62±2	56±2	56±2	60±2	60±2	62±2
Driven method	Direct driven	Direct driven	Direct driven	Direct driven	Direct driven	Direct driven	Direct driven	Direct driven	Direct driven	Direct driven
Start method	Υ-Δ	Υ-Δ	Υ-Δ	Υ-Δ	Υ-Δ	Variable frequency start	Variable frequency start	Variable frequency start	Variable frequency start	Variable frequency start
Length (mm)	1050	1050	1300	1300	1300	1050	1050	1300	1300	1300
Width (mm)	500	500	500	500	500	500	500	500	500	500
Height (mm)	1020	1020	1090	1090	1090	1020	1020	1090	1090	1090
Weight (kg)	145	190	200	220	230	145	190	200	220	230
